| 使用温度 | 加热炉：800~900 ℃回火炉：150~600 ℃ |
| 加热方式 | 电加热 (热风循环)燃气加热石墨加热 |
| 功能叙述与优点 | 均温度优良（±5℃）易调节工艺参数在加热室能自动控温和显示氧含量可依客户需求，提供炉内不同的充入气体和环境特殊保温节省能源消耗提供高纯度的气体环境，并减少气体消耗冷却可以选用油冷、水溶介质和盐浴冷却包括自动上料系统、清洗机、保护气氛淬火炉、回火炉、炉料分配系统利用计算机控制管理热处理生产工艺 |
| 使用于 | 渗碳碳氮共渗调质等热处理用于大批量的个种小零件的热处理 |
| 型号 | 工作区尺寸(mm)(W×L) | 生产能力 (kg/h) |
| CFH-01 | 500×3300 | 200 |
| CFH-02 | 610×4500 | 300 |
| CFH-03 | 750×5700 | 500 |
| CFH-04 | 750×6800 | 700 |
| CFH-05 | 910×8400 | 1200 |
| CFH -C | 依照需求客制化尺寸 | 依照需求客制化尺寸 |
| Temperature | Heating Furnace:800~900 ℃Tempering Furnace : 150~600 ℃ |
| Heating Method | Electric Heating (convection)Gas HeatingGraphite Heating (in higher temperature) |
| Advantage | Temperature Uniformity（±5℃）Easy to set up process parameterAutomatic temperature control and oxygen content in the chamberAccommodate reactive or insert gas atmospheres upon customer’s requestUltra-pure atmospheric environment with minimal gas consumptionCooling can choose oil cooling, water medium cooling, salt bath coolingInclude automatic loading and unloading system, cleaning machine, protected gas quenching furnace, tempering furnace, material distribution systemComputerize control and monitoring system for heat treatment process |
| Application | CarburizationCarbonitridingTempering Heat TreatmentHeat Treatment for small component in large batch |
| Type | Dimension (mm)(W×L) | Producing Capability (kg/h) |
| CFH-01 | 500×3300 | 200 |
| CFH-02 | 610×4500 | 300 |
| CFH-03 | 750×5700 | 500 |
| CFH-04 | 750×6800 | 700 |
| CFH-05 | 910×8400 | 1200 |
| CFH -C | Customized upon request | Customized upon request |
其它說明：
