| 加热方式 | 电加热 (热风循环)燃气加热石墨加热 |
| 优点 | 均温度优良（±5℃）快冷系统及预抽真空装置在加热室能自动控温和显示氧含量可依客户需求，提供炉内不同的充入气体和环境特殊保温节省能源消耗波形马弗和导流筒设计提高炉内均温度和减少热变形提供高纯度的气体环境，并减少气体消耗可整合其他设备如：清洗机、仓储系统、电脑管理和监视系统等 |
| 使用于 | 渗碳碳氮共渗气体渗氮特殊环境回火、退火 |
| 型号 | 尺寸(mm) (直径/高度) | 温度范围(℃) |
| PF/BF9-12 | 900/1200 | 750~1200 |
| PF/BF12-15 | 1200/1500 | 750~1200 |
| PF/BF17-23 | 1700/2300 | 750~1200 |
| PF/BF20-25 | 2000/2500 | 750~1200 |
| PF/BF-C | 依照需求客制化尺寸 | 100~1200 |
| Heating Method | Electric Heating (convection)Gas HeatingGraphite Heating (in higher temperature) |
| Advantage | Temperature Uniformity（±5℃）Rapid Cooling System and pre-vacuum deviceAutomatic temperature control and oxygen content in the chamberAccommodate reactive or insert gas atmospheres upon customer’s requestEnergy efficient design insulationWaved form muffle plus flow direct outer space design to improve uniformity and reduce thermal deformationUltra-pure atmospheric environment with minimal gas consumptionIntegrated with other automatic lines, such as: washing machines, stores, computerized systems for management and monitoring |
| Application | CarburizingCarbonitriding Gas nitridingTempering and Annealing in controlled atmosphere |
| Type | Dimension (mm)(ø/H) | Temperature Range(℃) |
| PF/BF9-12 | 900/1200 | 750~1200 |
| PF/BF12-15 | 1200/1500 | 750~1200 |
| PF/BF17-23 | 1700/2300 | 750~1200 |
| PF/BF20-25 | 2000/2500 | 750~1200 |
| PF/BF-C | Customized upon request | 100~1200 |
